SOURCE CODE ()

	' Enable colorfull bitmap graphic (up to 16 colors)

	BITMAP ENABLE(16)

	' Clear the screen

	CLS

	' Enable trigonometric functions using radiants.

	RADIAN

	' ugBASIC is an integer BASIC, so we need to
	' specify that some variables are floating point,
	' instead. Using the DIM instruction we can
	' declare the type of each variable.

	' This is the center of the screen.

	DIM cx AS FLOAT, cy AS FLOAT

	' These variables store the coordinates
	' of each point to draw, in a 3D reference system.

	DIM x AS FLOAT, y AS FLOAT, z AS FLOAT

	' These variables store the coordinates
	' of each point to draw, in a 2D reference system.

	DIM stx AS FLOAT, sty AS FLOAT

	' Calculate the "center" of the flag using
	' a proportional calculation with the original
	' values on the ZX spectrum resolution.

	cx=(SCREEN WIDTH / 2.0)
	cy=(SCREEN HEIGHT / 12.0)

	' Do nested loops.
	FOR ix=120 TO -19 STEP -4

		FOR iy=100 TO 1 STEP -4

		' Calculate the 3D coordinates.

		x = ix
		y = iy
		z = 30 + ( (10*SIN(x/11.0)) * COS(y/52.0) )

		' Transform them in a 2D projection.

		stx = cx+x-y:
		sty = cy+x/2+y/2+z

		' Draw the point on the screen.
		PLOT stx, sty
		PLOT stx, sty+1

		' Change the color on the flag based
		' on the abscissa of the 2D point.
		' (and avoid to draw the "star" if outside range).
		INK LIGHT RED
		IF x<(SCREEN WIDTH / 3.41) THEN INK LIGHT WHITE
		IF x<(SCREEN WIDTH / 16.0) THEN INK LIGHT GREEN
		IF x<(SCREEN WIDTH / 3.12) AND x>(SCREEN WIDTH / 3.76) THEN GOTO skip
		IF x<(SCREEN WIDTH / 10.66) AND x>(SCREEN WIDTH / 32.0) THEN GOTO skip

		' Draw the star around the point.
		' Fixed by Francesco Sblendorio here:
		' https://www.facebook.com/groups/2057165187928233/posts/4023940781250654/?comment_id=4025561614421904

		PLOT stx+1, sty+1
		PLOT stx, sty+2
		PLOT stx-1, sty+1
		PLOT stx, sty

skip:

		NEXT iy
	NEXT ix

Coleco Vision, Dina (Chuang Zao Zhe 50), SpectraVideo SV-603 VGA

In order to compile the example, type this command on the command line:

Linux

ugbc.coleco -O rom -o contrib_italian_flag.rom contrib_italian_flag.bas

Windows

ugbc.coleco.exe -O rom -o contrib_italian_flag.rom contrib_italian_flag.bas

For Microsoft Windows users we suggest using UGBASIC-IDE, which allows you to download and compile this example with just one click.

SEGA SC-3000

In order to compile the example, type this command on the command line:

Linux

ugbc.sc3000 -O rom -o contrib_italian_flag.rom contrib_italian_flag.bas

Windows

ugbc.sc3000.exe -O rom -o contrib_italian_flag.rom contrib_italian_flag.bas

For Microsoft Windows users we suggest using UGBASIC-IDE, which allows you to download and compile this example with just one click.

TRS-80 Color Computer 3

In order to compile the example, type this command on the command line:

Linux

ugbc.coco3 -O bin -o contrib_italian_flag.bin contrib_italian_flag.bas

Windows

ugbc.coco3.exe -O bin -o contrib_italian_flag.bin contrib_italian_flag.bas

For Microsoft Windows users we suggest using UGBASIC-IDE, which allows you to download and compile this example with just one click.

Thomson TO8

In order to compile the example, type this command on the command line:

Linux

ugbc.to8 -O k7 -o contrib_italian_flag.k7 contrib_italian_flag.bas

Windows

ugbc.to8.exe -O k7 -o contrib_italian_flag.k7 contrib_italian_flag.bas

For Microsoft Windows users we suggest using UGBASIC-IDE, which allows you to download and compile this example with just one click.
